What are the requirements for solder paste in the aerospace sector?

The technical requirements for solder pastes in the aerospace sector reflect the deep integration of cutting-edge materials science and engineering practice.The following is a systematic overview of the technical challenges, solutions and industry trends:

I. Technical Challenges and Response Strategies in Extreme Environments

Thermodynamic limit breakthrough

Phase change control technology: adopt gradient alloy design (e.g. AuSn-AgCu composite solder) to achieve step-by-step thermal stress release through the layered structure of metals with different melting points.

Thermal cycling accelerated testing: Development of life prediction model based on Arrhenius equation, combined with more than 1,000 times of cold and thermal shock test (-196℃~250℃) to verify material stability.

Mechanical Dynamics Adaptation

Microstructure Strengthening Mechanism: By doping silver nanoparticles (50nm), the yield strength of solder joints is increased to 520MPa while maintaining 8% elongation.

Vibration Spectrum Matching: A 6-degree-of-freedom shaker test system was established to cover 10-2000Hz broadband vibration and simulate the random vibration spectrum of the rocket launch phase.

Particle and ray irradiation.The space environment is filled with complex high-speed particles and high-energy rays.Their energy values are sufficient to destroy C-C bonds, C-O bonds and certain functional groups in polymer materials.These energetic particles can cause radiation damage to electronic components, solar cells, and polymer materials, resulting in ionisation, phonon excitation, or atomic displacement, which can lead to degradation and failure of the entire component.

II. advanced material system innovation

Precious metal composite solder

Optimisation of gold-based solder: development of Au88Ge12 (melting point 356°C) for spacecraft power supply system.

Brazing material innovation: adopting Ti-Zr-Cu-Ni system amorphous brazing material, realising 450℃ vacuum brazing, with joint airtightness up to 10^-9 Pa-m³/s.

Nano enhancement technology

Orientation Alignment Control: Applying magnetic field-assisted sintering technology, carbon nanotubes are axially aligned within the solder joints, and the electrical conductivity is increased to 65% IACS.

In-situ synthesis technology: TiB2 nanoparticles (particle size <100nm) are generated in the solder matrix with Vickers hardness up to HV220.

III. Intelligent Manufacturing and Quality Assurance System

Digital process control

Laser zone-selective melting: adopting 1070nm fibre laser to achieve 50μm welding joint precision and heat-affected zone control within 200μm.

Online monitoring system: integrating X-ray real-time imaging (resolution of 3μm) and thermal imaging camera (precision ±1℃) to achieve closed-loop control of welding process.

Full life cycle reliability management

Physical modelling of failure: Establishment of thermal fatigue life prediction model based on Coffin-Manson equation, with error rate <15%.

Space environment simulation: construction of a comprehensive test chamber, integrating multi-factor coupled tests such as 10^-6 Pa vacuum, 1 MeV electron radiation, atomic oxygen erosion, etc.

Industry technology evolution path:

Application of material genome programme: screening new solder compositions through high-throughput computation, shortening R&D cycle by 40

4D printing technology: developing shape memory solder to achieve self-healing function of micro-cracks during service.

Quantum Dot Reinforced Materials: Using the size effect of PbS quantum dots to prepare ultra-low melting point (120°C) high-strength solder.

Current technical bottleneck and breakthrough direction:

Space irradiation damage mechanism: need to establish Gd isotope labelling method to track the solder element migration law.

Microgravity welding dynamics: development of ultrasound-assisted vacuum brazing technology to overcome the molten metal wettability degradation problem

The technological development in this field has shifted from single performance optimisation to multi-physics field coupling design, and in the future, more attention will be paid to the synergistic innovation of materials-structures-processes, which will push the aerospace electronic system to miniaturisation, high integration and long-life direction of continuous evolution.
